RT-4060-4

RT-4060-4 is a PVC rafter tail with a long, shallow taper along the underside that ends in a small notch just beneath the square tip. The gentle slope keeps the tail slim, while the notch gives the end a sharp, finished edge. Nine sizes, for use with the HB PVC Soffit System or on its own.

SKU: RT-4060-4 Category: Tag:
Description

RT-4060-4 PVC Rafter Tail

A long taper makes a rafter tail look light; a crisp detail at the very end stops it from looking unfinished. RT-4060-4 combines the two, pairing an extended slope with a small notch at the tip. It is a decorative cellular PVC tail that reproduces exposed rafter ends below the eave and plays no part in the roof’s structure.

Long taper, notched tip

RT-4060-4 holds full depth for only about the first third of its length. From there, the underside rises in a long, gentle slope that covers most of the tail. Just before the end, a small notch is cut into the underside, leaving a short, shallow section that finishes in a square tip beneath the straight top edge.

It shares its notched tip with RT-4060-3, which uses a shorter, steeper cut that starts later, so RT-4060-4 is the slimmer and more streamlined of the two. RT-4030-7 has a similar long slope but ends in a level section without the notch. RT-4060-4 is a good fit for wide overhangs on coastal, West Indies and Key West homes, and also works for gable lookouts or under cantilevered decks.

How it is made

The tail is made by HB Elements in hollow-core cellular PVC, using its patented fabrication system. It is decorative and not designed to carry any load.

Installation uses the cleat and adhesive included with each tail. You can trim it to length on site and mount it over stucco, wood, cement fiber or, typically, cellular PVC soffit. It needs minimal prep before painting.

Completing the eave

Pair RT-4060-4 with HB soffit panels, such as the NJP-SL-5-12 shiplap nickel joint panel for long runs, to conceal panel seams and create a timber-framed look. With fascia and frieze board, the tails and panels form the full HB PVC soffit system; all items can also be bought separately.

Ordering and sizing help

Send a PDF set of plans to info@hbelementsinc.com or talk to HB on (954) 784-8216 about sizes and quantities. Standard dimensions are in the Rafter Tails Spec Sheet; compare other designs on the rafter tails page.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
