RT-4080-5

RT-4080-5 is a strongly sculpted PVC rafter tail: an early square step, a long level run, a steep angled rise and a final notch tucked under the square tip. Each change in the underside casts its own shadow, giving the eave a bold, carpentered look. Choose from nine sizes for HB soffit systems or standalone installation.

SKU: RT-4080-5 Category: Tag:
Description

RT-4080-5 PVC Rafter Tail

Exposed rafter ends on heavier timber-framed homes were often cut in several stages, each adding a line of shadow beneath the roof edge. RT-4080-5 recreates that layered effect in cellular PVC with four separate cuts along its underside. The tail is ornamental: it gives the overhang the appearance of exposed framing while the real rafters remain behind the soffit.

A layered, four-cut profile

Near the wall end, roughly a third of the way out, a square step lifts the underside. The tail then continues level at reduced depth until past its midpoint, where a steep angled rise begins. That rise stops at a small notch just under the end, and the tail finishes in a square tip with a straight top edge above.

Three neighboring designs help explain it. RT-4020-8 has the early step and level run but cuts straight to the tip. RT-4050-8 adds a level landing at the end instead of a notch. RT-4060-3 has the notched tip but no early step. RT-4080-5 brings together the early step and the notched tip, a strong choice for British West Indies, coastal and Key West homes with substantial eaves, as well as for gable lookouts and cantilevered decks.

Cellular PVC construction

Like every tail HB Elements makes, RT-4080-5 is hollow-core cellular PVC produced on the company’s patented fabrication system. Treat it as trim; it is not built to carry weight.

HB supplies a mounting cleat and adhesive with each tail. If the tail is too long for your overhang, it can be cut down during installation. Typical substrates are cellular PVC soffit, stucco, wood and cement fiber, and the surface is ready for paint with very little prep.

Working with HB soffit panels

Fitted across a ceiling of HB panels such as the NJP-5-12 nickel joint panel, the tails mask the joints between panels and give the overhang a timber-framed cadence. HB fascia and frieze board complete the soffit system, though every component, including this tail, can be purchased separately.

Ordering and sizing help

HB’s team can work out sizes and quantities from your drawings; send them as a PDF to info@hbelementsinc.com or phone (954) 784-8216. Standard dimensions for every tail are on the Rafter Tails Spec Sheet, and the complete set of profiles is on the rafter tails page.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
