RT-4093-6

RT-4093-6 is a PVC rafter tail with two square steps set close together near the wall, followed by a long, very shallow slope and a small notch under the square tip. The paired steps give a crisp double shadow line, while the long slope keeps the tail slender. Nine sizes for HB soffit systems or standalone use.

SKU: RT-4093-6 Category: Tag:
Description

RT-4093-6 PVC Rafter Tail

Doubling a step creates a stronger shadow than a single cut, and placing the pair near the wall leaves the rest of the tail free for a long, quiet slope. RT-4093-6 is designed around that contrast. It is an ornamental cellular PVC rafter tail that recreates exposed rafter ends, while the roof framing stays out of sight.

Paired steps and a long, shallow slope

RT-4093-6 keeps full depth for about a quarter of its length. Two square steps then lift the underside in quick succession, close enough to read as a pair. From the second step, the underside rises in a long, very shallow slope across most of the tail, ending at a small notch below the square tip.

The double step is what sets it apart. RT-4082-6 has a single early step before its slope, and RT-4022-8 spaces three square steps along the tail. RT-4093-6 groups its steps together and lets the slope do the rest, a good choice for long, low eaves on coastal and Key West homes. It also works for gable-end lookouts and under cantilevered decks.

Materials

Like the rest of HB Elements’ tails, RT-4093-6 is hollow-core cellular PVC produced with the company’s patented fabrication system. It is a trim piece, not a structural member.

A cleat and adhesive are supplied. Cut the tail to length on site if needed and attach it to cellular PVC soffit, stucco, wood or cement fiber. It is ready for paint after very little preparation.

Fitting it into an HB soffit

Combine RT-4093-6 with HB panels, such as the NJP-SL-5-10 shiplap nickel joint panel, so the tails mask the panel joints and add a timber-framed rhythm. HB fascia and frieze board complete the PVC soffit system; all components are also sold separately.

Ordering and sizing help

Send a PDF of your plans to info@hbelementsinc.com or call HB at (954) 784-8216 for help choosing sizes. Standard dimensions are in the Rafter Tails Spec Sheet; see all profiles on the rafter tails page.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
