RT-4705-6
RT-4705-6 is a PVC rafter tail with a hooked notch about a quarter of the way out, an S-shaped wave and a rounded shoulder that leads into a deep square end with no tip notch. Nine standard sizes, for HB soffit systems or standalone eave work.
RT-4705-6 PVC Rafter Tail
RT-4705-6 starts with a sharp hooked cut and ends with a full, solid tip, with a smooth wave linking the two. The contrast between the crisp notch and the heavy end gives it a carved, bracket-like character. It is made in decorative cellular PVC to recreate exposed rafters.
Hooked notch to a heavy end
About a quarter of the way from the wall, RT-4705-6 has a hooked notch cut into its underside. A short level stretch follows, then an S-shaped wave rises and rolls over into a deep square end. Unlike many waved tails, the tip has no notch and keeps its depth under the straight top edge.
RT-4612-6 opens with a similar hooked notch but tapers to a slim tip. RT-4701-7 shares the heavy end without the notch, and RT-4720-6 adds a deep notch at the tip. Bracket-style ends like this suit Spanish, Tuscan and Mission homes as well as pergolas.
How it is made and fitted
The tail is hollow-core cellular PVC, produced with HB Elements’ patented approach. It is a finish detail and must not be relied on for support.
A cleat and adhesive ship with RT-4705-6. Shorten it where the overhang is shallow, mount it on cellular PVC soffit, stucco, wood or cement fiber, and paint it once the surface is clean.
Soffit panel options
A slatted V-groove ceiling such as VGP-SL-5-08 gives a fine, lined backdrop for the heavier tail ends, which also cover panel seams. The HB soffit ceilings range includes fascia and frieze board; the tail is available by itself as well.
Sizing questions
Send elevations or sections in PDF to info@hbelementsinc.com for recommended sizes, or contact HB on (954) 784-8216. Standard dimensions appear in the Rafter Tails Spec Sheet, and the HB rafter tails page shows the full range.
