RT-4082-6
RT-4082-6 is a PVC rafter tail that pairs an early square step with a long, gentle slope and a small notch under the square tip. Compared with its steeper relatives, the slope does most of the work here, so the tail reads as lean and stretched-out. Nine sizes are available for HB soffit systems or independent use.
RT-4082-6 PVC Rafter Tail
Two tails can share the same set of cuts and still look quite different, depending on how much of the length each cut takes up. RT-4082-6 gives most of its length to a long, easy slope, making it the leaner sibling of HB’s more abrupt stepped designs. It is an ornamental cellular PVC tail that gives eaves the look of exposed rafter ends.
Short level run, long slope
About a quarter of the way out from the wall, a square step lifts the underside of RT-4082-6. A short level stretch follows, and before the midpoint the underside begins a long, gentle climb toward the end. The slope finishes at a small notch just below the tip, which ends square under a straight top edge.
The closest comparison is RT-4080-5: same step and notched tip, but a long level run and a short, steep rise. RT-4082-6 swaps those proportions, so its silhouette is gentler and slimmer. It suits wide eaves on coastal and Key West-style homes where a heavy stepped tail would feel too strong, and also serves as a gable lookout or under a cantilevered deck.
What it is made of
HB Elements forms RT-4082-6 from cellular PVC around a hollow core, using its own patented process. The tail is architectural trim and should not be asked to bear any load.
Installers receive a cleat and adhesive with every piece, and the tail can be shortened with ordinary tools if needed. It goes up against cellular PVC soffit most often, though stucco, wood and cement fiber also work, and it needs only light prep before painting.
Matching it to HB soffit panels
A gently sloped tail like this sits comfortably over a V-groove ceiling such as VGP-5-12. The tails also hide the joints between panels. For a finished eave, add HB fascia and frieze board from the soffit ceilings range; each part can be ordered on its own.
Ordering and sizing help
To get sizing advice, send a PDF of your drawings to info@hbelementsinc.com or speak to the team on (954) 784-8216. Standard tail dimensions are in the Rafter Tails Spec Sheet, and all profiles are shown on the rafter tails page.
| soffit-systems-variations | 3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″ |
|---|
