VGP-5-12

VGP-5-12 is the longest V-groove soffit panel HB Elements makes: a 12-foot, 1/2″ cellular PVC sheet with beveled V-joints every 5″ that reproduce tongue-and-groove soffit. Long sheets carry the groove lines further with fewer butt joints. Seven widths from 12″ to 48″.

SKU: VGP-5-12 Category:
Description

VGP-5-12 V-Groove PVC Soffit Panel (12 ft)

VGP-5-12 stretches HB’s tongue-and-groove pattern across 12 feet, the maximum length in the V-groove line. On long, straight eaves and wide porch ceilings, that means the grooves run unbroken for longer and fewer end joints interrupt the pattern.

Long V-groove lines

Chamfered V-joints run lengthwise every 5″ on VGP-5-12, the board rhythm of 1×6 tongue and groove. Over a 12-foot sheet the lines stay continuous across most of a typical eave section, which gives the ceiling a more orderly, plank-like appearance. The surface between grooves is smooth and takes paint or HB’s factory woodgrain finish.

Same length, different face: NJP-5-12 (square nickel joint) or SMP-5-12 (smooth). The shiplap V-groove equivalent is VGP-SL-5-12.

Where 12-foot V-groove makes sense

Choose the 12-foot sheet for full-length eaves, garage overhangs, deep wraparound porches and pool-cabana or lanai ceilings. Runs of 24 or 36 feet take exactly two or three sheets. Two installers are recommended for sheets this long; where ends meet, HB rafter tails can sit over the seam.

Shorter spaces are easier with VGP-5-10 or VGP-5-08.

Durable cellular PVC

Made from cellular PVC, VGP-5-12 resists moisture and mildew and, according to HB, will not split, check, crack or rot, nor expand and contract. HB sheets are fully usable with minimal waste, and paint lasts longer on PVC than on wood. Combine it with fascia, frieze board and HB PVC rafter tails for a complete soffit ceiling, or use it as vertical or horizontal wall cladding.

Ordering and sizing help

Email your plans in PDF to info@hbelementsinc.com and call (954) 784-8216 to settle widths, lengths and sheet counts. HB lists standard panel sizes in the Soffit Panels Spec Sheet.

Additional information
soffit-systems-variationsV-groove panel – 1/2″ x 12″ x 12′, V-groove panel – 1/2″ x 18″ x 12′, V-groove panel – 1/2″ x 24″ x 12′, V-groove panel – 1/2″ x 30″ x 12′, V-groove panel – 1/2″ x 36″ x 12′, V-groove panel – 1/2″ x 42″ x 12′, V-groove panel – 1/2″ x 48″ x 12′
