RT-4083-3
RT-4083-3 is a PVC rafter tail that keeps its full depth to about mid-length, then steps up, runs briefly level and rises in a moderate slope to a small notch beneath the square tip. Holding the detail back toward the end gives a solid tail with a carefully cut finish. Nine sizes for HB soffit systems or standalone use.
RT-4083-3 PVC Rafter Tail
When the inner half of a rafter tail stays plain, all the attention goes to the outer end. RT-4083-3 is built that way: the first half is a simple, full-depth block, and the shaping is concentrated in the half that projects furthest from the wall. It is a decorative tail in cellular PVC that imitates exposed rafter ends without being part of the roof structure.
Detail concentrated at the outer end
RT-4083-3 is full height with a straight top until roughly its midpoint. There a small step with a slanted face lifts the underside, followed by a brief level section. The underside then rises in a moderate slope and finishes at a small notch just short of the tip, which is cut square.
It has a close relative in RT-4083-5, which uses the same sequence but starts it about a third of the way out, giving a longer, gentler slope. RT-4070-4 is similar again but runs straight from its step into the slope with no level section. RT-4083-3 is the most compact of the three, a good fit for coastal, Florida Vernacular and West Indies homes that want sturdy-looking tails. It also works at gable lookouts and under cantilevered decks.
Construction notes
RT-4083-3 is a hollow-core cellular PVC tail made on HB Elements’ patented fabrication system. It is purely ornamental and carries no structural rating.
Fixing is by the cleat and adhesive that come with it. Trim it on site if your overhang is short, and fit it over cellular PVC soffit, stucco, wood or cement fiber. Paint follows with minimal surface prep.
Soffit panel pairing
Used over HB panels such as the NJP-5-08 nickel joint panel, RT-4083-3 tails cover the joints and set up a regular rhythm along the eave. Fascia and frieze board from HB’s soffit ceilings range complete the overhang, and all pieces are sold separately as well.
Ordering and sizing help
Email your plan set in PDF form to info@hbelementsinc.com and call (954) 784-8216 so HB can recommend sizes. Dimensions for the full range are in the Rafter Tails Spec Sheet; compare profiles on the HB rafter tails page.
| soffit-systems-variations | 3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″ |
|---|
