RT-4422-4
RT-4422-4 is a PVC rafter tail that climbs through three small steps along its underside before finishing in a hollow, cove-shaped end. The stepped run builds layered shadow, and the scooped tip ends it softly. Sold in nine standard sizes for HB’s soffit system or independent use.
RT-4422-4 PVC Rafter Tail
Stacking several small cuts ahead of a carved end gives a rafter tail the look of careful joinery. RT-4422-4 combines a three-step underside with a hollowed cove at the tip. It is cellular PVC trim that recreates exposed rafter ends; the structural framing stays concealed.
Three steps and a cove
RT-4422-4 is full height for a little over a third of its length. Two small steps then follow close together, a short level run leads to a third step past mid-length, and the tail continues level until the end, where a concave quarter-circle hollows out the tip and rises to a sharp top corner.
For the same cove after a single step, see RT-4420-5. RT-4222-5 also uses three steps but finishes with a rounded, outward-curving end instead of a hollow. RT-4422-4 suits British West Indies, Spanish Mediterranean and coastal homes where the eave is a feature, and also works for gable lookouts or beneath a deck.
Construction
RT-4422-4 is made by HB Elements from hollow-core cellular PVC on its patented fabrication system. It is non-structural and should be treated purely as trim.
A cleat and adhesive are packed with each tail. It can be cut down on site, fixed against cellular PVC soffit or over stucco, wood or cement fiber, and painted after light preparation.
Pairing with HB panels
With this much detail in the tail, a plain ceiling such as SMP-5-08 keeps the eave balanced, and the tails hide the seams between panels. HB fascia and frieze board finish the soffit ceilings system; tails are also sold separately.
Ordering and sizing help
Email a PDF of your plans to info@hbelementsinc.com or call (954) 784-8216 so HB can size the tails. Standard dimensions are in the Rafter Tails Spec Sheet, and every profile is on the rafter tails page.
| soffit-systems-variations | 3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″ |
|---|
