RT-4222-5

RT-4222-5 is a PVC rafter tail with three slanted steps climbing along its underside before a rounded end that stops at a short square face. The repeated steps give it a bumped, terraced outline, the most layered of HB’s stepped round-end tails. Nine sizes for HB soffit systems or standalone installation.

SKU: RT-4222-5 Category: Tag:
Description

RT-4222-5 PVC Rafter Tail

Each extra step on the underside of a rafter tail adds another line of shadow under the eave. RT-4222-5 uses three of them, spaced out ahead of a rounded end, for a terraced effect that reads clearly from the ground. Made from cellular PVC, it is a non-structural detail that only imitates exposed rafter ends.

Three steps and a rounded tip

RT-4222-5 holds full depth for a little over a quarter of its length. Three small slanted steps then lift the underside in turn, each followed by a short level run, so the bottom edge rises like a low staircase. Near the end the underside curves up in a convex arc and stops at a short square face at the tip.

It completes a set of three: RT-4220-4 has one step before the same rounded end, RT-4221-5 has two, and RT-4222-5 has three. More steps mean a busier, more crafted profile, a good fit for British West Indies, coastal and Key West homes where the eave is meant to stand out. It can also serve as a gable lookout or sit under a cantilevered deck.

Material and fitting

HB Elements makes RT-4222-5 from hollow-core cellular PVC on its patented fabrication system. It is purely decorative and is not intended to carry weight.

Each tail arrives with a cleat and adhesive. It can be cut shorter during installation and fixed to cellular PVC soffit, stucco, wood or cement fiber. Paint goes on after minimal preparation.

Pairing with HB panels

With this much detail in the tail, a plain ceiling such as the SMP-5-10 smooth panel keeps the overall look balanced. The tails also cover the panel seams. Add fascia and frieze board to complete the HB PVC soffit system, or order the tails by themselves.

Ordering and sizing help

For a recommendation, send PDF drawings to info@hbelementsinc.com or call (954) 784-8216 so HB can recommend sizes. Standard dimensions are in the Rafter Tails Spec Sheet, and the rafter tails page shows every profile.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
