RT-4281-3

RT-4281-3 is a PVC rafter tail that keeps its full depth to about mid-length, then steps up, runs level and finishes with an S-shaped curve into a notch under the square tip. Holding the detail toward the end gives a solid tail with a molded finish. Nine sizes for HB soffit systems or standalone use.

SKU: RT-4281-3 Category: Tag:
Description

RT-4281-3 PVC Rafter Tail

Keeping a rafter tail at full depth for longer makes it look sturdier, and saves the decoration for the part furthest from the wall. RT-4281-3 follows that approach, ending in a reverse curve and notch. HB produces it in cellular PVC as a decorative element that recreates exposed rafter ends.

A sturdy body with a molded end

For close to half its length, RT-4281-3 is a full-depth block with a straight top. A small slanted step then lifts the underside, followed by a short level run. The end rises in an S-shaped curve, hollow and then rounded, and finishes at a notch under the square tip.

Compared with RT-4280-5, which has the same curve but starts its step a quarter of the way out, RT-4281-3 keeps more full-depth body and a more compact end. For a rounded end with a notch instead of an S-curve, see RT-4250-4. It suits larger coastal, Mediterranean and West Indies homes and can also be used at gable ends or beneath a deck.

Material and fitting

RT-4281-3 is hollow-core cellular PVC, produced on HB Elements’ patented fabrication system. It is decorative trim and should not be used structurally.

Each tail is supplied with a cleat and adhesive. Shorten it if needed and fix it over cellular PVC soffit, stucco, wood or cement fiber, then paint with minimal prep.

Completing the soffit

Run RT-4281-3 along a soffit of HB panels such as the NJP-5-10 nickel joint panel, so the tails mask the seams and add a steady, timber-framed rhythm. HB fascia and frieze board finish the soffit ceilings system; tails are also sold separately.

Ordering and sizing help

Email a PDF of the plans to info@hbelementsinc.com or phone (954) 784-8216 to work out sizes with HB. Standard sizes are in the Rafter Tails Spec Sheet; more designs are on the rafter tails page.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
