RT-4290-7

RT-4290-7 is a multi-cut PVC rafter tail: two square steps along the underside, the first near the wall and the second past mid-length, followed by a concave curve that rises to a notch under the square tip. The combination of steps and curve gives a richly layered profile. Nine sizes for HB soffit systems or standalone use.

SKU: RT-4290-7 Category: Tag:
Description

RT-4290-7 PVC Rafter Tail

Combining straight steps with a curve gives a rafter tail both crisp shadows and a soft finish. RT-4290-7 uses two steps to build up to a curved, notched end, creating one of the more detailed profiles in HB’s range. It is a decorative cellular PVC tail that gives the eave the appearance of exposed rafters.

Two steps, then a curve

About a fifth of the way from the wall, a square step lifts the underside of RT-4290-7. A long level run follows, then a second square step a little past mid-length. From there the underside curves upward in a concave arc to a notch, leaving a small ledge beneath the square tip.

It builds on RT-4270-4, which has a single step before a similar arc and notch, by adding a second step. For a stepped tail with a straight slope instead of a curve, see RT-4093-6. RT-4290-7 suits British West Indies, coastal and Key West homes where the eave is a feature, and also works for gable lookouts and cantilevered decks.

Construction details

RT-4290-7 is made from hollow-core cellular PVC on HB Elements’ patented fabrication system. It is purely ornamental and carries no loads.

A cleat and adhesive come with each tail. It can be shortened on site and fitted to cellular PVC soffit, stucco, wood or cement fiber. It is ready for paint after light prep.

With HB soffit panels

A detailed tail like this pairs well with a quiet ceiling such as the SMP-5-08 smooth panel, and the tails conceal the panel seams. Complete the eave with HB fascia and frieze board from the PVC soffit system, or buy the tails separately.

Ordering and sizing help

For sizing, send PDF drawings to info@hbelementsinc.com or call HB on (954) 784-8216. The Rafter Tails Spec Sheet has standard dimensions, and every profile is on the HB rafter tails page.

Additional information
soffit-systems-variations3 1/2″ x 5 1/2″ x 24″, 3 1/2″ x 5 1/2″ x 30″, 3 1/2″ x 5 1/2″ x 36″, 4 1/2″ x 9 1/2″ x 24″, 4 1/2″ x 9 1/2″ x 30″, 4 1/2″ x 9 1/2″ x 36″, 4″ x 7 1/2″ x 24″, 4″ x 7 1/2″ x 30″, 4″ x 7 1/2″ x 36″
