RT-4690-4
RT-4690-4 is a PVC rafter tail with three cuts on its underside: a step about a third out, a second step past the midpoint and a notch under the square tip, with an S-curve between the last two. Nine standard sizes for HB soffit systems or standalone use.
RT-4690-4 PVC Rafter Tail
RT-4690-4 steps down its underside in stages, so the tail appears to be built up from several layers. Two steps lead into a wave, and a notch finishes the tip. It is one of the more detailed cellular PVC tails in the HB range and, like the rest, is decorative rather than structural.
Three cuts in sequence
About a third of the way from the wall, the underside of RT-4690-4 drops its first step. A second step follows past the midpoint, then a short flat and an S-curve that rises to the end, where a notch is cut beneath the square tip under the straight top edge.
With one step instead of two, the outline becomes close to RT-4683-2 or RT-4680-2. The extra step spreads the detail along more of the tail, which suits Spanish Colonial, Mission and other elevations where richer eave carving is appropriate.
What goes into it
RT-4690-4 is fabricated from cellular PVC with a hollow core under HB Elements’ patented process. It adds detail to the eave and is not designed to bear loads.
Install it with the cleat and adhesive that come in the box. It can be cut back for a shorter projection and fixed to PVC soffit, stucco, wood or cement fiber, ready for paint after minimal prep.
With HB soffit panels
A nickel joint ceiling such as NJP-5-08 gives a simple, lined backdrop for the stepped tails, which also conceal panel seams. HB fascia and frieze board complete the soffit ceilings system, though the tail can be bought separately.
Get a size proposal
Send PDF elevations or sections to info@hbelementsinc.com and HB will recommend sizes, or call (954) 784-8216. Standard dimensions are given in the Rafter Tails Spec Sheet, and the HB rafter tails page shows all designs.
